Graphite Electrode Rp
Graphite Electrode Rp Description
The main raw material for RP graphite electrodes is high-quality petroleum coke, which is mainly used for steel making in electric arc furnaces. The production process includes calcination, batching, kneading, molding, roasting, graphitization, and processing. The raw materials of graphite electrodes are needle coke and high-quality petroleum coke, and the production process includes one impregnation and two roastings.
The Specifications of Graphite Electrode Rp
Standard Sizes of Electrode: If special specification requirements exist, both sides consult supply & demand.
| Items | Unit | Nominal diameter(mm) | ||||
| 100~200 | 250~300 | 350~600 | 780-1400 | |||
| Specific resistance | Electrode | μΩ·m | 7.5~8.5 | 7.5~8.5 | 7.5~8.5 | 8.5~10.5 |
| Nipple | 5. 8~6.5 | 5. 8~6.5 | 5. 8~6.5 | 5.8~6.5 | ||
| Transverse strength | Electrode | MPa | ≥10.0 | ≥9.0 | ≥8.5 | ≥7.0 |
| Nipple | ≥16.0 | ≥16.0 | ≥16.0 | ≥16.0 | ||
| Elastic modulus | Electrode | GPa | ≤9.3 | ≤9.3 | ≤9.3 | ≤12.0 |
| Nipple | ≤13.0 | ≤13.0 | ≤13.0 | ≤13.0 | ||
| Ash content | Electrode | % | ≤0.3 | ≤0.3 | ≤0.3 | ≤0.3 |
| Nipple | ||||||
| Bulk density | Electrode | g/m³ | 1.55~1.64 | 1.55~1.64 | 1.55~1.63 | 1.55~1.63 |
| Nipple | ≥1.74 | ≥1.74 | ≥1.74 | ≥1.74 | ||
| C.T.E | Electrode | 10-6℃ | ≤2.4 | ≤2.4 | ≤2.4 | ≤2.4 |
| Nipple | ≤2.0 | ≤2.0 | ≤2.0 | ≤2.0 | ||
If there are special specification requirements, both sides consult supply and demand.
Graphite Electrode Rp Video
Requirements For Surface Quality Of RP Graphite Electrodes
Surface Quality
1. There are no more than two defects or holes on the surface of the electrode and the size shall not exceed the value in the following table.
|
SPECIFICATION SIZE |
NOMINAL DIAMETER OF GRAPHITE ELECTRODE (MM) |
||
|
75-225 |
250-400 |
450-800 |
|
|
Diameter(mm) |
10-20 |
20-30 |
30-40 |
|
Depth(mm) |
3-5 |
5-10 |
10-15 |
2. There is no transverse crack or longitudinal crack with width of 0.3-1.0 on the surface of the electrode. The length of longitudinal crack is not more than 5% of the perimeter of the electrode. The crack with width less than 0.3mm shall be ignored.
3. The width of black skin area on the surface of the electrode is less than 1/10 of the perimeter of the electrode and its length is less than 1/3 of the length of the electrode.
FAQ
Q: What about your delivery date in normal conditions?
A: We send the cargo within 15 days after receiving the deposit.
Q: what about your package?
A: Usually as per customer's requests.Common packing information: small size in bundles, big size in bulksome sizes with plastic capstan to protect both ends, seaworthy packaging.
Q: If products have some quality problem, how would you deal with it?
A: We will be responsible for all of our quality problems.
Q: How can you control your quality?
A: For each production processing, ZhenAn has a complete QC system for the chemical composition and Physical properties. After production, all the goods will be tested, and the quality certificate will be shipped along with the goods.
