RP150 Graphite Electrode
Length: 1600mm-2700mm
Bulk Density: 1.6g/cm3--1.8g/cm3
Resistance: 4.5---6
Diameter: 100mm---700mm
Transport Package: Wooden Case
Specification: diameter 100mm-500mm
Production Capacity: 3000 Tons Each Month
RP150 Graphite Electrode Description
The rp150 arc furnace electrodes graphite electrode products are characterised by a number of significant advantages, including strict consumption control, low resistivity, low ash content, high temperature strength, low thermal expansion coefficient, good thermal conductivity and electrical conductivity, a compact structure, high oxidation resistance, and high mechanical stability. the product contains up to 80% uhp needle coke. the uhp rp150 arc furnace electrodes graphite electrode is suitable for use in modern arc furnaces, and its main properties are of significant importance for achieving economical consumption rates.
The Specification Of RP150 Graphite Electrode
| Item | Unit | Graphite Electrode | ||||
|---|---|---|---|---|---|---|
| RP | ||||||
| φ300-φ800mm | ||||||
| Typical Value | ||||||
| Resistivity | Electrode | μΩm | 7.0-10.0 | |||
| Nipple | 4.0-4.5 | |||||
| Modulus of Rupture | Electrode | Mpa | 8.0-10.0 | |||
| Nipple | 19.0-22.0 | |||||
| Young's Modulus | Electrode | GPa | 7.0-9.3 | |||
| Nipple | 12.0-14.0 | |||||
| Bulk Density | Electrode | g/cm3 | 1.53-1.56 | |||
| Nipple | 1.70-1.74 | |||||
| CTE (100-600ºC) | Electrode | 10-6/ºC | 2.2-2.6 | |||
| Nipple | 2.0-2.5 | |||||
| Ash | % | 0.5 | ||||
FAQ
Q: What is your delivery time?
A: It depends on the size/complexity of your order and our production schedule. Usually, we provide a faster delivery than the industry's average.
Q: What is the payment term?
A: Our payment terms are negotiable.
Q: I have some special requirements about specifications.
A: We have a well-rounded product range, which endows us with the capability of applying many special specifications. Please feel free to contact us with yours.
Q: Do you accept OEM services?
A: Yes, we do.
